Description
- Technical Data
- Directives and standards
- Safety instructions
Technical data
Operating conditions | ||
| Maximum traversing speed vmax | 5 m/s | |
| Acceleration amax. | 500 m/s2 | |
| Shock | (EN 60068-2-27) | 500 m/s2 /11 ms |
| Vibration | (EN 60068-2-6) | 100 m/s2 (57Hz - 200Hz) |
| 1,5 mmp-p (10Hz - 57Hz) | ||
| Operating temperature | 0 ... 80°C | |
| Storage-/ transport temperature | -10 ... 80°C | |
| Relative air humidity during storage | max. 95% | |
| Relative air humidity in operation | max. 80% at 20°C | |
| Protection type | (EN 60529) | IP67 |
| EMV | EN 61326-1 | |
| EN 61000-6-3 / EN 61000-6-4 | ||
| RoHS compliant | yes | |
| UL compliant | Cable UL AWM STYLE 20549 | |
| Casting compound UL 94VO | ||
Information
At a glance
Compact
- Construction-space neutral, integrated measuring head electronics
- Sizes 15, 20, and 25 in six runner block designs
- Runner block accessible from all sides (lubrication, cleaning)
Flexible
- Magnetic strip can be installed across rail joints
- Length finishing with manual tools
- Compatible with the full BSHP product range
- Compatible with the braking and clamping elements, bellows, front seals and front lube units
- Flexible cable output in all directions
Robust
- Protection type IP67 without buffer air and encapsulation
- Dirt-resistant magnetic measuring principle
- Circumferential gaskets for protection against dirt and media
- Sensors shielded by steel bodies
- Measurement close to and stiff at the tool center point
Cost-effective
- Mount & Guide & Measure: fully adjusted Plug & Play complete system
- Favorable component price
- No additional assembly or disposition required
Future-proof
- Global service and spare parts from the BSHP modular system
- Compatible with all established drive controllers and measuring displays
- Easy replacement
Powerful
- Repeat accuracy: ±1 µm
- System accuracy: ±20 µm/m
- Voltage supply: 10…30 V
- Incremental: 1Vpp (1 mm) and TTL (10 µm) reference track, pitch-coded
- Highly dynamic: up to 5 m/s
- Measuring length: up to 17,8 m
- Several scanners can be mounted on one rail
Encoders and other interfaces which are suitable for drive-integrated safety technology are currently being prepared and are available on request.
Certification
Directives and standards
Safety Instructions
Safety instructions
Downloads
 | IMScompact integrated measuring system for BSHP ball rail system Manual | R320103196_EN | 2019-12-01 | English | PDF | 2.5MB Product Groups: Integrated measuring systems |
| R999001485 Integrated measuring system IMScompact Catalog | R999001485 | 2020-03-01 | English | PDF | 2.9MB Product Groups: Integrated measuring systems Only available as PDF |
