Артикул: RX7083
В наличии
Power supply module VT 11116-1X
Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.
Не отвечаем 5 минут — скидка на весь заказ!
Нужна скидка? Звони — сделаем лучшее предложение
Работаем по всей России
Возможны самовывоз и доставка по всей территории России
Надежность
Профессиональная поддержка
Description
- Component series 1X
Features
- The power supply module provides two stabilized voltages. It is intended for the supply of external electric actuators.
- 24 V / ±10 V
- Switching power supply unit
- Reverse polarity protection
- Functional control by LED display
- Output voltages are galvanically separated from the operating voltage
Type code
| 01 | 02 | 03 | 04 | |
| VT 11 | – | 1X | * |
| 01 | Power supply module | VT 11 |
| 24 V power supply module | ||
| 02 | Output voltage ±15 V | 006 |
| Output voltage ±10 V | 116 | |
| 03 | Component series 10 ... 19 (10 ... 19: unchanged installation and connection dimensions) | 1X |
| 04 | Further details in the plain text | |
Technical data
General
| Component series | 1X |
Operating voltage
| Operating voltage 1) | UB | 21.5 Veff to 35 Veff | ||
| Three phase bridge (winding) | U | 21.5 V to 35 V | ||
| Full bridge (winding) | U | 20 V to 24 V | ||
| Power consumption | P | VA | ≤ 10 | |
| Output voltage | UO | ±10 V (± 1%) | ||
| Output current, max. | I | mA | ± 150 | |
| 1) | only with external smoothing capacitor, 2200 μF per module |
Other information
| Residual ripple | related to nominal output voltage | % | < 1 | |
| Temperature range | t | °C | -25 … +70 | |
| Weight (approx.) | m | kg | 0.13 | |
(For applications outside these values, please consult us!)
Downloads
 | 供电模块 Data Sheet | RC29729 | 2009-11-30 | Chinese | PDF | 383k Product Groups: Power supply and stabilizing units 类型 VT 11006，VT 11116 |
| Netzversorgungsmodul Data Sheet | RD29729 | 2009-11-30 | German | PDF | 263k Product Groups: Power supply and stabilizing units VT 11006, VT 11116 |
| Fuente de alimentación Data Sheet | RS29729 | 2009-11-30 | Spanish | PDF | 263k Product Groups: Power supply and stabilizing units VT 11006, VT 11116 |
| Power supply module Data Sheet | RE29729 | 2009-11-30 | English | PDF | 1.7MB Product Groups: Power supply and stabilizing units VT 11006, VT 11116 |
| Module d'alimentation secteur Data Sheet | RF29729 | 2009-11-30 | French | PDF | 263k Product Groups: Power supply and stabilizing units VT 11006, VT 11116 |
