Axial piston variable pump A4VG series 32

Name: Axial piston variable pump A4VG series 32
Brand: Bosch Rexroth
SKU: RX7730

Цена по запросу

Получить КП

Подберем решение под ваши задачи

Поможем выбрать подходящий вариант, проверим совместимость и подготовим коммерческое предложение

Имя

E-mail

Фамилия

Телефон

Указать реквизиты организации или ИП

Комментарий к запросу

Вы можете добавить файлы с реквизитами компании, спецификацией или ТЗ

Мною прочитаны и я даю согласие с документом Политика конфиденциальности

Не отвечаем 5 минут — скидка на весь заказ!

sale@boschrexroth-russia.ru

Нужна скидка? Звони — сделаем лучшее предложение

+7 495 137-07-02

Работаем по всей России

Возможны самовывоз и доставка по всей территории России

Надежность

Профессиональная поддержка

Description

High pressure pump for applications in closed circuits
Size 28 … 250
Nominal pressure 400 bar
Maximum pressure 450 bar
Closed circuit

Features

Integrated boost pump for boost and pilot oil supply
Flow direction changes when the swashplate is moved through the neutral position
High-pressure relief valves with integrated boost function
With adjustable pressure cut-off as standard
Boost-pressure relief valve
Through drive for mounting of further pumps up to same nominal size
Large variety of controls
Swashplate design

Technical data

Table of values

Size				28	40	56	71	90	125	180	250
Displacement geometric, per revolution		Vg max	cm³	28	40	56	71	90	125	180	250
Nominal pressure		pnom	bar	400	400	400	400	400	400	400	400
Maximum pressure		pmax	bar	450	450	450	450	450	450	450	450
Maximum speed	at Vg max	nnom	rpm	4250	4000	3600	3300	3050	2850	2500	2400
Maximum speed	Intermittent 1)	nmax	rpm	5000	5000	4500	4100	3800	3450	3000	2700
Flow	at Vg max and nnom	qV nom	l/min	119	160	202	234	275	356	450	600
Power	at qV nom and Δpnom 2)	P	kW	79	107	134	156	183	238	300	400
Torque	at Vg max and Δpnom	M	Nm	178	255	357	452	573	796	1146	1592
Weight (approx.)		m	kg	29	31	38	50	60	80	101	156

1)	At Δp = 70 … 150 bar or Δp < 300 bar and t < 0.1 s
2)	Δpnom = 400 bar

Downloads

	Axialkolben-Verstellpumpe A4VG Baureihe 32 Manual \| RD92003-01-B \| 2015-12-01 \| German \| PDF \| 1.3MB Product Groups: Variable pumps, closed circuit, Variable pumps, closed circuit Betriebsanleitung
	Axial Piston Variable Pump A4VG, Series 32 Manual \| RE92003-01-B \| 2015-12-01 \| English \| PDF \| 1.3MB Product Groups: Variable pumps, closed circuit, Variable pumps, closed circuit Instruction manual
	Pompa a pistoni assiali a cilindrata variabile A4VG Serie 32 Manual \| RI92003-01-B \| 2015-12-01 \| Italian \| PDF \| 2.7MB Product Groups: Variable pumps, closed circuit, Variable pumps, closed circuit Istruzioni d’uso
	Аксиально-поршневой регулируемый насос A4VG Серия 32 (Европа) Manual \| R-RS92003-01-B \| 2015-12-01 \| Russian \| PDF \| 1.5MB Product Groups: Variable pumps, closed circuit Инструкция по эксплуатации
	Pompe à pistons axiaux à cylindrée variable A4VG Manual \| RF92003-01-B \| 2015-12-01 \| French \| PDF \| 1.3MB Product Groups: Variable pumps, closed circuit, Variable pumps, closed circuit
	Аксиально-поршневой регулируемый насос A4VG Серия 3 (Европа) Data Sheet \| R-RS92003 \| 2021-08-11 \| Russian \| PDF \| 6.7MB Product Groups: Variable pumps, closed circuit Номинальный размер 28–125
	Axial piston variable pump A4VG series 32 Asia Pacific Data Sheet \| RE-P92003 \| 2021-08-11 \| English \| PDF \| 7.4MB Product Groups: A4VG/32 High-pressure pump for applications in closed circuits
	Axial piston variable pump A4VG series 32 Europe Data Sheet \| RE-E92003 \| 2021-08-11 \| English \| PDF \| 6.8MB Product Groups: A4VG/32 High-pressure pump for applications in closed circuits
	Axialkolben-Verstellpumpe A4VG Baureihe 32 Europa Data Sheet \| RD-E92003 \| 2021-08-11 \| German \| PDF \| 6.8MB Product Groups: A4VG/32 Hochdruckpumpe für Anwendungen im geschlossenen Kreislauf
	可変容量形アキシアルピストンポンプ A4VG シリーズ 32 Data Sheet \| RJ-J92003 \| 2017-02-01 \| Japanese \| PDF \| 4MB Product Groups: Variable pumps, closed circuit, Variable pumps, closed circuit アジア太平洋（日本版）
	Axial piston variable pump AA4VG Series 32 – America version Data Sheet \| RE-A92003 \| 2018-06-01 \| English \| PDF \| 4.7MB Product Groups: Variable pumps, closed circuit, Variable pumps, closed circuit High-pressure pump for applications in a closed circuit
